304/1.4301 Stainless Steel Coil
Stainless steel coil 300 series, in addition for decorative purposes, is widely used in building materials, kitchen utensils, pipe and industrial uses, among them 304 is the most representative.
Products Categories
Get A Free Quote
304/1.4301 Stainless Steel Coil Technical
| Type | Int’l Standard | Steel Designation | Main Chemical Compositions | Mechanical Properties | ||||
| Cr | Ni | Proof Stress (N/mm2) | Tensile Strength (N/mm2) | Elong- ation | HRB | |||
| 304 | ASTM A240-96 | UNS S30403 | 18.00 ~20.00 | 8.00~12.00 | ≧ 170 | ≧ 485 | ≧ 40 | ≧ 92 |
| 304 | ASME SA240-95 | UNS S30403 | 18.00 ~20.00 | 8.00~12.00 | ≧ 170 | ≧ 485 | ≧ 40 | ≧ 92 |
| 304 | CNS G3163-93 | 304L | 18.00 ~20.00 | 8.00~13.00 | ≧ 175 | ≧ 480 | ≧ 40 | ≧ 90 |
| 304 | JIS G4303-91 | SUS 304L | 18.00 ~20.00 | 8.00~13.00 | ≧ 175 | ≧ 480 | ≧ 40 | ≧ 90 |
| 304 | EN 10088:1995 | 1.4306 | 18.00 ~20.00 | 8.00~12.00 | ≧ 200 | 500 ~ 650 | ≧ 45 | |
| 304 | DIN 17440:1996 | 1.4306 | 18.00 ~20.00 | 8.00~12.00 | ≧ 180 | 460 ~ 680 | ≧ 40 | |
Commonly used specification of Stainless Steel Coil
HOT ROLLED STAINLESS STEEL COIL
| Thickness | Width | Surface |
| 2.5.0mm ~ 28.0mm | 1220MM ~ Max. 2300mm | NO.1 |
COLD ROLLED STAINLESS STEEL COIL
| Thickness | Width | Hardness |
| 0.1mm ~ 0.4mm | Could be negotiable for small strips,max.300mm | 1/4H ; 3/4H ; 1/2H ; FULL HARD |
| 0.5mm ~ 3.0mm | 1220mm ~ Max. 1540mm | |
